1channel BNC input & 1 channel BNC looped output, NTSC / PAL (Auto adapt)
Analog video level meter, peak video signal level, SYNC signal level, Color bar chroma level measurement
PTZ control, RS485 control, Baud 600 - 115200bps, compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic etc
CVBS loop test: the tester send and receive color bar generator signal, check BNC cable |
CVBS |
|
IP Discovery / Quick ONVIF / IPC test / RTSP play / Client APK / Auto HD, automatically recognize type of HD input signal
Rapid Video: Auto log in and view the video, create testing report
Hik test tool: activate hikvision camera, modify the user name, password and IP parameters
Dahua test tool: Dahua camera test, modify the user name, password and IP parameters
|
IP camera test 4k / H.265 / H.264 |
|
IP & CVBS test at the same time, converter test from analog to digital with dual test window
|
IP & CVBS test |
|
8MP TVI camera test, 3840x2160P 15 FPS, UTC control / call OSD menu
8MP CVI camera test, 3840x2160P 12.5 / 15 FPS, UTC control d call OSD menu
8MP AHD test, 3840x2160P 15 FPS, UTC control d call OSD menu
|
Coaxial HD test |
| 1channel HDMI input, support 1080P |
HDMI input |
| 4x zoom, to enlarge image, Screen snapshot, record, save, view and record and playback |
Zoom Image |
| Color bar generator: Output one channel PAL / NTSC color bar video signal for testing monitor or video cable |
Analog Video out |
DC24V / 2A power out
PoE power output: 48V PoE power output, max power 24W
DC12V power: DC12V / 3A power output
UTP cable test: Test UTP cable connection status and display on the screen. Read the number on the screen
RJ45 cable TDR test: Test cable pair status, length, attenuation, reflectivity, and impedance, skew etc. .measurement range 180M |
Power output |
| screen projection: tester, mobile phone and PC display at the same time (For android version mobile phone) |
Tester Play |
Trace route, Link monitor, DHCP server, port flashing, Ping test
|
Network test |
| Built in WIFI, speeds 150M, display wireless camera image |
Wi-Fi |
| Detect the surrounding Wi-Fi signal and signal strength, support 2.4G and 5G frequency band |
WIFI Analyzer |
| 1channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone |
Audio test |
| Captures and analyzes the command data from controlling device, also can send hexadecimal |
Data monitor |
| Measurement POE switch or PSE power supply voltage and cable connection status |
PoE test |
| You can select PoE power switch, IP setting, CVBS, LAN info, HDMI IN functions etc in any interface |
Drop-down menu |
| DC 12V 2A |
External power supply |
| Built-in 7.6V lithium polymer battery, 7500mAh |
Battery |
| after charging 3.5~4 hours, normal working time 16 hours |
Rechargeable |
| OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese etc |
Operation setting |
| 1-30min |
Auto OFF |
| 10°C~50°- |
Working Temperature |
| 90% ~ 30% |
Working Humidity |
| 240x154x46 mm |
Dimension |
| 620g |
Weight |
