Main Processor: MC6630
Operating System: Embedded Linux |
System |
Normal Mode: 8x(TVI / AHD: 5MP@12fps; AHD / TVI / CVI: 4MP@15fps; AHD / TVI: 3MP@18fps; AHD / TVI / CVI: 1080P / 720P; Analog: 960H), 4x Analog (5MP) + 5x Network (5MP), 6x Analog (5MP) + 3x Network (5MP)
Network: 16x 5MP / 4MP / 3MP / 1080P / 960P / 720P (Total incoming bandwidth ≤48M) |
Video Input |
| 8CH BNC |
Input |
| Analog / AHD / CVI / TVI 2.0 / TVI 3.0 / Network |
Video Signal Type |
| 1HDMI, 1VGA, CVBS |
Output |
Input: 2 Channel, RCA
Output: 1 Channel, RCA |
Audio |
Input: 4CH
Output: 1CH |
Alarm |
| 8Channel (Max 16 channel in pure network mode) |
Motion Detection |
| Recording, Email, Screen tips, Buzzer, Push notification (motion detection) |
Trigger Events |
| Yes |
AI Human Detection |
Interface: RS485
Protocol: Pelco-D, Pelco-P
Baud Rate: 110~921600
Address: 0~255 |
PTZ |
VGA Resolution: 1920x1080P / 60Hz, 1280x1024 / 60Hz, 1280x720 / 60Hz, 1024x768 / 60Hz
HDMI Resolution: 1920x1080P / 60Hz, 1280x1024 / 60Hz, 1280x720 / 60Hz, 1024x768 / 60Hz
Display Split: 16 Channel / 9 Channel / 8 Channel / 4 Channel / 1 Channel
Privacy Masking: 3 Rectangular Zones (Each camera)
OSD: Camera title, Time, Video loss, Alarm, Motion detection, Recording |
Display |
| H.265+ / H.265 / H.264+ / H.264 |
Video Compression |
| G.711U / G.711A |
Audio Compression |
| 5MP_Lite (1952x1296), 4MP_Lite (1440x1280), 3MP_Lite (1536x1024), 1080N (1080x960), 720P (1280x720), 960H (P: 960x576 / N:960x480) |
Recording Resolution |
| Lowest / Low / Ordinary / Good / Better / Best |
Recording Video Quality |
Analog: PAL / NTSC: 5MP_Lite (1952x1296 8x6fps), 4MP_Lite (1440x1280 8x8fps), 3MP_Lite (1536x1024 8x10fps), 1080N (1080x960 8x15fps), 720P (1280x720 8x15fps)
Pure IP (H.265):
PAL: 5MP @8x25fps, 4MP and lower @12x25fps
NTSC: 5MP @8x30fps, 4MP and lower @12x30fps |
Record Rate |
| Manual / Timer / Motion Detection / Alarm Input |
Record Mode |
| 2CH 1080P @30fps |
Playback Decode Capability |
Pure Analog: 4CH: 960H @25fps, 720P @15fps, 1080N @15fps, 5MP_Lite @6fps, 4MP_Lite @8fps, 3MP_Lite @10fps
Mixture mode: 4CH 720P @25fps, 2CH 1080P @25fps, 1CH 5MP @25fps
Pure Network: 4CH 720P @25fps, 2CH 1080P @25fps, 1CH 5MP @25fps |
Sync Playback |
| 4Channel / 1Channel |
Remote Playback |
| All, Channel, Manual, Time, Date, Motion Detection, Alarm, Motion and Alarm |
Search Mode |
| Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward / back, Digital zoom, Full screen |
Playback Functions |
| 4Channel |
Smart Phone Playback |
| USB Device (with format FAT 32) / Network / FTP |
Backup Mode |
| 1x RJ45 10/100M Adaptive Ethernet Interface |
Network Interface |
| TCP / IP, HTTP, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
Network Protocols |
| Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE, HDPROVN |
DDNS |
| Edge, IE8-11, Google Chrome, Firefox, Safari |
Web Browser |
| Support Windows 7 / Windows 8 / Windows 10 |
CMS Software |
| CIF / D1 (1-12fps) |
Extra Stream |
| iPhone, iPad, Android, Android pad |
Smart Phone |
| 1x SATA Interface |
Hard Disk Interface |
| 1x SATA Hard Disk (2.5" / 3.5", Up to 8TB) |
Hard Disk Capacity |
| Hebrew, Arabic, Russian, French, Spanish, Simplified Chinese, Traditional Chinese, Polish, Czech, Thai, Bulgarian, Japanese, German, Portuguese, Turkic, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese |
Language |
| Yes |
UTC Control |
| 2x USB2.0 Interfaces |
USB Interface |
| DC 12V / 2A ≤6W (Without Hard Disk) |
Power Consumption |
| 55°~10°- / 90%~10 |
Working Environment |
| 260x215x43 mm |
Dimension (WxDxH) |
| 2kg (Without HDD) |
Weight |
