N6MB01 |
Hardware |
16x PoE IP camera |
IP Video Input |
Cameras with built-in mic |
Audio Input |
VGA, HDMI |
Video Output |
HDMI: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1280x720, 1024x768
|
Display Resolution |
1channel, RCA
|
Audio output |
H.264, H.265
|
Video Format |
7680x2160, 4608x1728, 4512x2512, 4096x3072, 3840x2160, 2560x2560, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p |
Live View / Playback Resolution |
Up to 4 channels |
Synchronous Playback |
SATA: 2x SATA interface (1x 4TB HDD included) Capacity: Up to 12TB (Max. 6TB capacity for each HDD |
HDD |
2x USB2.0 |
USB Interface |
1x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface for LAN/WAN 16x RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera |
Network Interface |
Max. Power Per Port: 25W Supported Standard: IEEE 802.3af/at |
PoE |
HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP |
Network Protocols |
Edge, Firefox, Chrome, Safari |
Browsers Supported |
PC: Windows, Mac OS; Smartphone: iOS, Android |
OS Supported |
Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts) |
Maximal User Access |
DC 48V~54V |
Power Supply |
10W (without HDD & PoE)> |
Power Consumption |
Temperature: -10°C~45°C Humidity: 10%~90% |
Working Environment |
330x45x285 mm |
Dimensions |
2.4kg |
Weight |
