| H.264 |
Compression Format |
| Yes (For IP Channels) |
ONVIF |
| All in 1 Hybrid (AHD / CVI / TVI / CVBS + IP) |
Format |
Max IP: 0CH Standard BNC + 12CH IP (Over Network)
Max Analog: 8CH Standard BNC + 4CH IP (Over Network) |
Video Input |
| HDMI (4K, 1920x1080), VGA (1280x1024, 1024x768), CVBS(Spot) |
Video Standard Output |
Two Way Audio
Input: 4CH RCA (2.0 Vp-p, 1kΩ)(+IP Cameras)
Output: 1CH RCA ( 2.0 Vp-p, 1kΩ) |
Audio |
Channels & Resoultion: Max 8CH 5MP Non-Real-Time (With 4CH IP)
Recording Modes: Schedule, Manual, Motion, Sensor
5MP: Up to 10FPS Per Channel
4MP: Up to 15/12FPS Per Channel
2MP and lower: 30/25FPS Per Channel
960H: 30/25FPS Per Channel |
AHD Recording |
Channels & Resolution: Max 12CH 4MP Real-Time
Recording Modes: Schedule, Manual, Motion, Sensor, Analytics
4MP and lower: 30/25FPS Per Channel
|
IP Recodring |
Local / Remote: 8CH / 9CH
Search Mode: Time-Slice, Time, Event, File Management |
Playback |
1USB 2.0 Port + 1USB 3.0 Port
Backup Format: AVI/DAT |
Backup |
HD Analog Stream: Master Stream 1-10FPS@5MP / 1-12/15FPS@4MP / 1-25/30FPS@1080P; Sub-Stream Up to 1-25FPS@1080P
CVI Stream: Master Stream 1-25/30FPS@1080P; Sub-Stream Up to 1-25FPS@1080P
Analog Stream: Master Stream 1-25/30FPS@960H; Sub-Stream Up to 1-25/30FPS@D1
IP Stream: Master Stream 1-25/30FPS@4MP; Sub-Stream Up to 1-25/30FPS@D1
Master Stream: Up to 24Ch@Recording Resolution
Browser: Safari (Mac OS) IE (Windows Vista/7/8/10)
CMS: Yes
Mobile Application: Provision Cam2 for iOS/ Android
User Access: 5 Users Online with Professional Autorithy Management |
Remote Application |
Input: 4CH (+IP Cameras)
Output: 1CH (+IP Cameras)
|
Alarm |
| HDD: 2 SATA (Up to 8TB) with smart management |
Storage |
Connection: RS-485 / CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
PTZ |
Ethernet: 100Mbps (RJ-45)
Protocol: TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P
Bandwidth: Incoming: 60Mbps (For 12 IP Channels) / 32Mbps (For 4 IP Channels) Outgoing: 60Mbps |
Network |
| 375x275x45mm |
Dimension (W*D*H) |
| Yes |
IR Controller |
| 12V/3A |
Power Supply |
| 0°C~50°C |
Operation Temperature |
