| Yes |
NDAA Compliant |
| H.265 (HEVC) / H.264 |
Compression Format |
| Yes (For IP Channels) |
ONVIF |
| All in 1 Hybrid (AHD / CVI / TVI / CVBS + IP) |
Format |
Max IP: 0CH Standard BNC + 10CH IP (Over Network)
Max Analog: 8CH Standard BNC + 2CH IP (Over Network) |
Video Input |
| HDMI (1920x1080), VGA (1280x1024, 1024x768) |
Video Standard Output |
Two Way Audio
Input: 1CH RCA (2.0 Vp-p, 1kΩ)(+IP Cameras)
Output: 1CH RCA ( 2.0 Vp-p, 1kΩ) (+IP Cameras) |
Audio |
AHD / TVI / CVI: 2MP Lite / 1MP: Up to 12/15 FPS Per Channel
CVBS: 960H: Up to 30/25 FPS Per Channel
IP: 2MP / 1MP: Up to 25/30FPS Per Channel
Master Streams over Network: Up to 4Ch@Recording Resolution (Up to 18Mbps) |
Main Stream |
HD Analog: 1-25/30FPS@D1 Per Channel (FPS Restricted to Master Stream FPS)
CVBS / IP: 1-25/30FPS@D1 Per Channel |
Sub Stream |
User Access: 5 Users Online with Professional Authority Management
Recording Modes: Schedule, Manual, Motion, Sensor, Analytics, POS
Applications: Provision Cam2 for iOS/Android, IE for Windows 7/8/10, Safari for Mac OS, CMS for Windows/MAC |
General Recording |
Incoming: 16Mbps
Outgoing: 60Mbps |
Bandwidth |
Local / Remote: 8CH / 4CH
Search Mode: Time-Slice, Time, Event, File Management, Smart Search |
Playback |
For HD Analog Cameras: Line Crossing (No Direction Choice), Sterile Area
For IP Cameras: Line Crossing (With Direction Choice), Sterile Area, Object Monitoring, Camera Tampering, Smart Search |
Analytics |
2USB 2.0 Port
Backup Format: AVI/DAT |
Backup |
| IP Cameras Only |
Alarm (Input/Output) |
| HDD: 1 SATA (Up to 6TB) |
Storage |
Connection: CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
PTZ |
Ethernet: 100Mbps (RJ-45)
Protocols: TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P, POS |
Network |
| 255x220x43mm |
Dimension (W*D*H) |
| 12V/2A |
Power Supply |
| 0°C~50°C |
Operation Temperature |
