| Yes |
NDAA Compliant |
| H.265 (HEVC) / H.264 |
Compression Format |
| Yes (For IP Channels) |
ONVIF |
| All in 1 Hybrid (AHD / CVI / TVI / CVBS + IP) |
Format |
Max IP: 0CH Standard BNC + 6CH IP (Over Network)
Max Analog: 4CH Standard BNC + 2CH IP (Over Network) |
Video Input |
| HDMI (1920x1080), VGA (1280x1024, 1024x768) |
Video Standard Output |
Two Way Audio
Input: 1CH RCA (2.0 Vp-p, 1kΩ)(+IP Cameras)
Output: 1CH RCA ( 2.0 Vp-p, 1kΩ) |
Audio |
Channels & Resolution: Max 4CH 1080P Lite Real-Time (With 2CH IP)
Recording Modes: Schedule, Manual, Motion, Sensor
2MPL (1080P Lite) and lower: 30/25FPS Per Channel
960H: 30/25FPS Per Channel |
AHD Recording |
Channels & Resolution: Max 6CH 1080P Real-Time
Recording Modes: Schedule, Manual, Motion, Sensor, Analytics
2MP and lower: 30/25FPS Per Channel
|
IP Recording |
Local / Remote: 4CH
Search Mode: Time-Slice, Time, Event, File Management |
Playback |
2USB 2.0 Port
Backup Format: AVI/DAT |
Backup |
HD Analog Stream: Master Stream 1-25/30FPS@720P/1080P Lite; Sub-Stream Up to 1-25FPS@D1
Analog Stream: Master Stream 1-25/30FPS@960H; Sub-Stream Up to 1-25FPS@960H
IP Stream: Master Stream 1-25/30FPS@1080P; Sub-Stream Up to 1-25/30FPS@D1
Master Stream: Up to 6Ch@Recording Resolution
Browser: Safari (Mac OS) IE (Windows Vista/7/8/10)
CMS: Yes
Mobile Application: Provision Cam2 for iOS/ Android
User Access: 5 Users Online with Professional Authority Management |
Remote Application |
| None Integral (IP Cameras Only) |
Alarm (Input / Output) |
| HDD: SATA (Up to 6TB) |
Storage |
Connection: CoC / IP-Over Network
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Supported Controls: Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus |
PTZ |
Ethernet: 100Mbps (RJ-45)
Protocol: TCP/IP, DHCP, DDNS, NTP, SMTP, RTSP, HTTPS, FTP, SNMP, P2P, POS
Bandwidth: Incoming: 10Mbps / Outgoing: 30Mbps |
Network |
| 255x220x43mm |
Dimension (W*D*H) |
| Yes |
IR Controller |
| 12V/2A |
Power Supply |
| 0°C~50°C |
Operation Temperature |
