Main Processor ARM Cortex A7 Processor
Operating System Embedded Linux |
System |
| 8Ch (8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 1280x1024 / 960p / 720p / D1 / CIF) |
Video Input |
| 1x HDMI |
Video Output |
| 64Kbps |
Audio Bit Rate |
| G711U, G711A |
Audio Compression |
| Motion Detection 8 Channel, MD Zones: 396 (22x18), Trigger Events Recording, Email, FTP, Snapshot and Screen Tips |
Alarm |
| 1920x1080 / 1280x1024 / 1280x720 / 1024x768 |
HD Output |
| 8Ch / 6Ch / 4Ch / 1Ch |
Display Split |
| Yes |
Digital Zoom |
| Camera Title, Time, Recording, Motion Detection, Event Alarm |
OSD |
| H.265+ / H.264+ / H.264 / H.265 |
Video Compression |
PAL: 4K and lower @ 8Ch x 25fps
NTSC: 4K and lower @ 8Ch x 30fps |
Recording Resolution Rate |
| Manual / Timer / Motion Detection / Smart Event |
Record Mode |
| 1Ch 4K@30fps, 2Ch 4MP@30fps, 4Ch 1080P@30fps, 8Ch 720P@30fps |
Local Sync Playback |
| 1080P (1920x1080) @ 120fps |
Decode Capability |
| Yes |
Remote Sync Playback |
| All, Timing Video, Motion Detection, Tag Search, Smart Event, Picture, Log |
Search Mode |
| Play, Pause, Fast Forward, Rewind, Previous Frame, Next Frame, Electronic Zoom, Clip, Audio |
Playback Functions |
| USB Device / Network |
Backup Mode |
| 1x RJ45 10M/100M (self-adaptive ethernet interface) |
Network Interface |
Incoming: 72Mbps
Outgoing: 48Mbps |
Bandwidth |
| IPv6 / TCP / IP, HTTP, HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p, PPPoE |
Network Protocols |
| Profile S, Profile T |
ONVIF |
| Edge, IE8-11, Google Chrome, Firefox, Safari |
Web Browser |
| Support Windows 7 / Windows 8 / Windows 10 / Windows 11 / Mac OS |
CMS Software |
| Yes |
Cloud Support |
| iPhone, Android |
Smartphone |
| 4x Independent 100Mbps PoE Network Interfaces (Output power AT mode 30W per port), 45/78 line order, Total Power Output≤ 45W, Support Plug and Play, Support network cable extended mode Max. 200m |
PoE |
1x SATA Hard Disk Interface (3.5" SATA)
Capacity: Up to 8TB |
Storage |
| 2x USB2.0 |
USB Interface |
| DC 48V / 1.36A ≤ 6W (Without Hard Disk and PoE) |
Power Consumption |
| 10°C ~ 50°C, 10%~90% (humidity)- |
Working Environment |
| 200x175x40 mm |
Dimension |
| 1.5kg |
Net Weight (Without HDD) |
| 1/3" Progressive Scan CMOS Sensor |
Image Sensor |
| 4MP |
Resolution |
| 2560x1440 |
Effective Pixels (HxV) |
| H.264 / H.265 / JPEG / AVI / MJPEG |
Compression |
| G711A / U, AAC |
Audio Compression |
| PAL / NTSC |
TV System |
| Color: 0.04 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
Minimum Illumination |
| Auto: 1/3 - 1/100000sec |
Electronic Shutter Time |
| 60dB |
S/N Ratio |
| Progressive |
Scanning System |
| 3.6mm |
Lens |
| Horizontal: 73°, Vertical: 40°, Diagonal: 88° |
Field of View |
Supplement Light: 42μ x2 PCS; Distance: 25m
Status: Auto Control; Power On: Smart, Manual & Timed Mode |
Night Vision |
| RJ-45 (10/100 Base-T) |
Ethernet |
| TCP /IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, SMTP, UDP, QoS, 802.1x |
Network Protocol |
| Support ONVIF 19.12 (Profile S/T) |
ONVIF |
| Internal, Support IEEE 802.3af |
PoE |
| Main Stream 1: 2560x1440, Main Stream 2: 1920x1080, Main Stream 3: 1280x720, Sub Stream 1: 720x480, Sub Stream 2: 640x360, Sub Stream 3: 352x288@ 25FPS |
Stream |
| IE 8-11, Google Chrome, Firefox, Mac Safari |
Browser |
| iPhone, Android |
Smartphone |
| Intrusion Detection (based on human detection), Motion Detection based on human detection |
Intelligent Analysis |
| Color / B&W (IR-CUT) |
Day / Night |
| Saturation / Brightness / Contrast / Sharpness, Mirror, 3D DNR, White Balance, Anti Flicker, HLC, Distortion |
Image Config |
| Support |
BLC |
| DWDR |
WDR |
| 3Rectangular Zone |
Privacy Masking |
| NVR / CMS / Web |
Recording Mode |
| Hebrew, English, Arabic, French, Spanish, Italian, Ukrainian, Chinese, Korean, Polish, Japanese, Portuguese, Vietnamese, Thai, Hungarian |
Language |
| Built-in Mic |
Audio |
Temperature: -20°C to 50°C
Humidity: 95% or less |
Operating Conditions |
Temperature: -20°C to 60°C
Humidity: 95% or less |
Storage Conditions |
DC12V ±10%, 700mA
|
Power Source |
Plastic, IP66
|
Housing, Protection |
174x68x70 mm
|
Dimensions |
183g
|
Weight |
