| 4ch |
IP Video Input |
| 4MP |
IP Video Resolution |
| 60Mbps |
Input Bandwidth |
| 1ch, RCA (2.0 Vp-p, 10kΩ) |
Audio Input |
| 1ch, 4k (3840x2160) / 30Hz, 1920x1080 / 60Hz, 1280x1024 / 60Hz, 1280x720 / 60Hz |
HDMI Output |
1ch, 1920x1080 / 60Hz, 1280x1024 / 60Hz, 1280x720 / 60Hz
HDMI / VGA simultaneous output |
VGA Output |
| 60Mbps |
Output Bandwidth |
| G.711A, G.711U |
Audio Decoding Format |
| H.265, H.264 |
Video Decoding Format |
| 1ch, RCA (2.0 Vp-p, 10kΩ) |
Audio Output |
| 4MP, 3MP, 1080P, 720P, D1 |
Recording Resolution |
| 4ch @1080P (30fps) |
Decoding Capability |
| Video, Video & Audio |
Stream Type |
|
Record Mode: Normal, Alarm
Playback Mode: Instant, Channel, File, Tag
Sync Playback, Up to 4-ch
Backup Mode: USB device
|
Recording Management |
| 1RJ45, 10Mbps / 100 Mbps auto-negotiation Ethernet port |
Ethernet Port |
| HTTP, HTTPS, WebSockets, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, DDNS |
Network Protocol |
| Supports iOS, Android |
Mobile Client |
| Plug-in free live view: Chrome, Edge, Opera |
Web Browser |
|
Ports: 4 Rj45, 10Mbps / 100Mbps auto-negotiation Ethernet ports
Standard: IEEE 802.3af
Power: ≤40W
|
PoE |
HDD interface: 1 SATA 3.0 interface
Capacity: Up to 10 TB capacity |
HDD |
| 2x USB 2.0 |
USB Port |
| 51V DC, 1.25A |
Power |
| 200x200x48 mm |
Dimension |
| 510g |
Weight |
| CCC, CE, FCC, RoHS, UKCA |
Certification |
| Desk mounting, Wall mounting |
Installation Method |
Operating Temperature: 0°C~40°C
Storage Temperature: -30°C~70°C |
Temperature |
Operating Humidity: 10%~90% RH (non-condensing)
Storage Humidity: 5%~95% RH (non-condensing) |
Humidity |
| CMOS 1/3" Sensor |
Image Sensor |
| ICR type |
Day & Night |
| Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
Bracket Angle Adjustment |
| 4mm |
Focal Length |
| F2.2 |
Aperture |
| Horizontal: 74.9°, Vertical: 41.3°, Diagonal: 88.2° |
Field of View |
| 1IR Light |
Supplementary Light |
| Up to 30m (depending on environment) |
Supplementary Light Distance |
| 850nm |
IR Wavelength |
| Black & White Mode |
Night Vision Mode |
Encoding Format: H.265, H.264
Main Stream:2560x1440, 2304x1296, 1920x1080
Sub Stream: 640x360, 352x288, 320x240
Frame Rate: 1-25 FPS, Default 25fps
|
Video Specifications |
Encoding Format: G.711A, G.711U
Sampling Rate: 8kHz |
Audio Specifications |
| 1RJ45, 10Mbps / 100Mbps auto-negotiation Ethernet port |
Ethernet Port |
| Plug-in free live view: Chrome, Edge, Opera |
Web Browser |
Image Enhancement: DWDR, BLC, 3D DNR
Privacy Mask: 4 Areas
|
Image |
Motion Detection, Human Detection
|
Smart Detection |
Audio Input: Built-in MIC
|
Interface |
| POE: IEEE 802.3af |
Power |
| 106.8x 106.8x 90.5mm |
Dimension |
| 174g |
Weight |
| Ceiling mounting |
Installation Method |
Operating Temperature: -10°C~50°C
Storage Temperature: -40°C~70°C |
Temperature |
Operating Humidity: 10%~95% RH (non-condensing)
Storage Humidity: 3%~95% RH (non-condensing) |
Humidity |
