| NVS8 |
Model |
| 8x PoE IP camera |
IP Video Input |
| Cameras with built-in mic |
Audio Input |
| VGA, HDMI |
Video Output |
|
HDMI: 4096x3072, 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
VGA: 1920x1080, 1280x1024, 1280x720, 1024x768
|
Display Resolution |
|
1channel , RCA
|
Audio output |
|
H.264, H.265
|
Video Format |
| 4096x3072, 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p |
Live View / Playback Resolution |
| Up to 4 channels |
Synchronous Playback |
SATA: x1 SATA interface (1x 2TB HDD included)
External HDD: 1 eSATA interface for HDD
Capacity: Up to 12TB (Max. 6TB capacity for each HDD
|
HDD |
2x USB2.0
|
USB Interface |
1x RJ-45 10/100 Mbps self-adaptive Ethernet interface for LAN/WAN
8x RJ-45 10/100 Mbps self-adaptive PoE ethernet interface for IP camera |
Network Interface |
Max. Power Per Port: 25W
Supported Standard: IEEE 802.3af/at |
PoE |
| HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP |
Network Protocols |
| Edge, Firefox, Chrome, Safari |
Browsers Supported |
| PC: Windows, Mac OS; SmartPhone: iOS, Android |
OS Supported |
| Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts) |
Maximal User Access |
| DC 48~53V |
Power Supply |
| 10W (without HDD & PoE)> |
Power Consumption |
Temperature: -10°C~45°C
Humidity: 10%~90% |
Working Environment |
| 255x49.5x232 mm |
Dimensions |
| 1.4kg |
Weight |
| CMOS 1/3" Sensor |
Image Sensor |
| 2560x1440 (4 Megapixels) at 22 FPS |
Video Resolution |
| f= 4.0 mm fixed, F= 2.0 |
Lens |
| H.264 |
Video Format |
|
horizontal: 150°, vertical: 44°
|
Field of View |
|
Auto-switching with IR cut filter
|
Day & Night |
|
Up to 30 meters (LED 6pcs / 20mil / 850nm)
|
Infrared Night Vision |
|
Spotlights: 8pcs / 5W / 6500K / 560 Lumens
|
Color Night Vision |
| Two-way audio |
Audio |
| IEEE 802.3af, 48V Active |
PoE |
| 12V/2A, <12W |
DC Power |
Power: DC power port
System: Reset button
Ethernet: One 10M / 100Mbps; RJ45
Storage: Micro SD card slot (Max. 256GB)
Audio: Built-in microphone and speaker |
Interface |
Mainstream: 2fps - 25fps (default: 22fps)
Substream: 4fps - 15fps (default: 10fps) |
Frame Rate |
Mainstream: 1024Kbps - 5120Kbps (default: 4096Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps) |
Code Rate |
| Edge, Chrome, Firefox, Safari |
Browser Supported |
| PC: Windows, Mac OS; Smartphone: iOS, Android |
OS Supported |
| Motion detection / person detection / vehicle detection |
Smart Alarm |
| Motion-triggered recording (default); scheduled recording; 24/7 recording |
Record mode |
| HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P |
Protocols & Standards |
| 20Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams) |
Maximal User Access |
| 10°C ~ 55°C- |
Operating Temperature |
| 90%~10% |
Operating Humidity |
| IP66 |
Waterproof |
195x103x56 mm
|
Size |
| 650g |
Weight |
