| 1/3" Progressive Scan CMOS Sensor |
Image Sensor |
| 4MP |
Resolution |
| 2560x1440 |
Effective Pixels (HxV) |
| H.264 / H.265 / JPEG / AVI / MJPEG |
Compression |
| G711A / U, AAC |
Audio Compression |
| PAL / NTSC |
TV System |
| Color: 0.04 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR |
Minimum Illumination |
| Auto: 1/3 - 1/100000sec |
Electronic Shutter Time |
| 60dB |
S/N Ratio |
| Progressive |
Scanning System |
| 2.8mm |
Lens |
| Horizontal: 95°, Vertical: 53°, Diagonal: 114° |
Field of View |
Supplement Light: 42μ x2 PCS; Distance: 25m
Status: Auto Control; Power On: Smart, Manual & Timed Mode |
Night Vision |
| RJ-45 (10/100 Base-T) |
Ethernet |
| TCP /IP, IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, SMTP, UDP, QoS, 802.1x |
Network Protocol |
| Support ONVIF 19.12 (Profile S/T) |
ONVIF |
| Internal, Support IEEE 802.3af |
PoE |
| Main Stream 1: 2560x1440, Main Stream 2: 1920x1080, Main Stream 3: 1280x720, Sub Stream 1: 720x480, Sub Stream 2: 640x360, Sub Stream 3: 352x288@ 25FPS |
Stream |
| IE 8-11, Google Chrome, Firefox, Mac Safari |
Browser |
| iPhone, Android |
Smartphone |
| Intrusion Detection (based on human detection), Motion Detection based on human detection |
Intelligent Analysis |
| Color / B&W (IR-CUT) |
Day / Night |
| Saturation / Brightness / Contrast / Sharpness, Mirror, 3D DNR, White Balance, Anti Flicker, HLC, Distortion |
Image Config |
| Support |
BLC |
| DWDR |
WDR |
| 3Rectangular Zone |
Privacy Masking |
| NVR / CMS / Web |
Recording Mode |
| Hebrew, English, Arabic, French, Spanish, Italian, Ukrainian, Chinese, Korean, Polish, Japanese, Portuguese, Vietnamese, Thai, Hungarian |
Language |
| Built-in Mic |
Audio |
Temperature: -20°C to 50°C
Humidity: 95% or less |
Operating Conditions |
Temperature: -20°C to 60°C
Humidity: 95% or less |
Storage Conditions |
DC12V ±10%, 700mA
|
Power Source |
Plastic, IP66
|
Housing, Protection |
Ø109.4x88.5 mm
|
Dimensions |
176g
|
Weight |
