| CMOS 1/2.8" Sensor |
Image Sensor |
| Default: 3840x2160 (8 Megapixels) at 25 FPS |
Video Resolution |
| f= 5.3-86mm, zoom module |
Lens |
| 16X |
Optical Zoom |
| H.265 |
Video Format |
|
Horizontal: 3.6°-54.2°
Vertical: 2.1°-41.7°
|
Field of View |
|
Auto-switching with IR-cut filter
|
Day & Night |
|
Up to 80m (LED 7pcs / 28mil / 850nm)
|
Infrared Night Vision |
| Two-way audio |
Audio |
| Pan: 360°, Tilt: 0°~90° |
Pan & Tilt Range |
Pan Speed: 1.4°-281° /s
Tilt Speed: 1.4°-56° /s
(speed can be set) |
Pan & Tilt Speed |
| 64 |
Pan & Tilt Preset |
| 1patrol; up to 32 presets per patrol |
Pan & Tilt Patrol |
| Available |
Auto Tracking |
| Support |
Power-Off Memory Function |
| IEEE 802.3 at, 48V Active |
PoE |
| DC 12V 2A, <24W |
DC Power |
Mainstream: 2fps - 25fps (default: 25)
Substream: 4fps -15fps (default: 10)
|
Frame Rate |
Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps) |
Code Rate |
| Edge, Chrome, Firefox, Safari |
Software Browsers Supported |
| PC: Windows, Mac OS; Smartphone: iOS, Android |
Software OS Supported |
| Motion detection, person detection, vehicle detection, pet detection |
Smart Alarm |
| Motion-triggered recording (default); scheduled recording; 24/7 recording |
Record Mode |
| HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P |
Protocols & Standards |
| Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts) |
Maximal User Access |
| Google Assistant |
Work with |
Power: DC power port
System: Reset button
Ethernet: One 10M/100Mbps RJ45
Storage: MicroSD card slot (Max. 256GB)
Audio: Built-in microphone and speaker |
Interface |
| 10°C to 50°C- |
Operating Temperature |
| 90%~10% |
Operating Humidity |
| IP66 |
Waterproof |
| Φ132x281 mm |
Dimension |
| 1.6kg |
Weight |
