| "1/2.8 CMOS |
Image Sensor |
| Default: 3840x2160 (8MP) at 25 FPS |
Video Resolution |
| 3x optical zoom |
Zoom |
| f=2.8 - 8mm, zoom module |
Lens |
| H.265 |
Video Format |
Horizontal: 50° ~ 94°
Vertical: 30° ~ 53° |
Field of View |
Horizontal: 355°
Vertical: 0°~50°
Auto Tracking: Support |
Pan/Tilt Angle |
| IR-cut filter with auto switching |
Day & Night |
| Up to 12 meters (LED: 12pcs / 14mil / 850nm) |
Infrared Night Vision |
| Spotlights: 4pcs / 2.7W / 6500K / 180Lumens |
Color Night Vision |
| Two-Way Audio |
Audio |
| IEEE 802.3af, 48V Active |
PoE |
| DC 12.0V - 1A, <12W |
DC Power |
Φ85x118mm
|
Dimension |
| 395g |
Weight |
DC power port
Ethernet: One 10M / 100Mbps RJ45
Micro SD Card Slot (Max. 256GB)
Built-in Microphone and Speaker
Reset Button |
Interface |
Mainstream: 2fps - 25fps (default: 25fps)
Substream: 4fps - 15fps (default: 10fps) |
Frame Rate |
| HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, P2P, FTP |
Protocols & Standards |
Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps) |
Code Rate |
| 20Users (1 admin & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams) |
Maximal User Access |
| Edge, Chrome, Firefox, Safari |
Browsers Supported |
| PC: Windows, Mac OS; Smartphone: iOS, Android |
OS Supported |
| Motion Detection / Person Detection / Vehicle Detection / Pet Detection |
Smart Alarm |
| Motion recording (default); Scheduled recording; 24/7 recording |
Record Mode |
| Google Assistant |
Works With |
Operating Temperature: -10°C~50°C
|
Temperature |
Operating Humidity: 10% ~ 90%
|
Humidity |
| IP64 |
Waterproof |
